AG240i Row Crop Dozer Blade

The AG240i blade includes the features of the AG240 blade system and is designed to attach onto OEM and Grouser FH400 Front Hitches. These systems are ideal for 150–500 horsepower row crop tractors.

Features

• Quick connect & disconnect at the front hitch
• Easy adjustable skid shoes
• Available for mounting on OEM or aftermarket front hitches
• Custom nameplate

Specifications

• 2-4-6 way control options
• Reversible cutting edge: 5/8″ x 6″
• Widths: 10′, 12′, 14′, 16′
• 30″–32″ lift height
• Blade height: 60″
• Moldboard: 3/16″ thick
• Angle cylinder: (2) 5″ x 12″
• Tilt cylinder: 4″ x 8″
• Blade angles: 30° right or left
• Blade tilts: 10°

Attachments/Options

• End extensions
• Box end plates – angled
• Top extension for end
• Box end plates – straight
• LED light kit
• Additional top extension
• Weight carrier bracket
• Single level multi coupler
• 4-point to CAT3N adapter
